MODEL |
MP300 |
MP450 |
MP650 |
MP900 |
| INPUT |
VOLTAGE，FREQUENCY |
AC100-240V (AC85~264V or DC120~370V),50/60Hz(47-63Hz
or DC) |
| CURRENT（110V/220V） |
3.7A typ / 2.0A typ |
5.7A typ /3.1A typ |
8.0A typ / 4.2A typ |
11A typ / 5.7A typ |
| POWER FACTOR |
0.99 typ (AC IN 110V, Io=100%)/0.95
typ (AC IN 220V, Io=100%) |
| EFFICIENCY（110V/220V） |
74% typ / 78% typ |
75% typ / 78% typ |
77% typ / 80% typ |
77% typ / 80% typ |
| LEAKAGE CURRENT |
0.5A max(AC IN 110V, Io=100%),0.95A
max(AC IN 220V, Io=100%) |
| INRUSH CURRENT |
15A typ(AC IN 110V, Io=100%),30A typ(AC
IN 220V, Io=100%) at cold start |
| OUTPUT |
NUMBER OF SLOTS |
4 |
5 |
5 |
6 |
| TOTAL POWER（110V/220V） |
250 / 300 |
400/450 |
600/650 |
800/900(peak
1k) |
| RISE TIME |
500 Max(AC IN 100V Io=100%) |
| HOLDING TIME |
20 typ(AC IN 100V Io=100%) |
| OUTPUT |
AUXILIARY POWER |
12V / 0.1A (Only used for remote ON/OFF
function |
| ALARM |
FAN alarm, LINE alarm |
| ELECTRIGALLY ISOLATED |
INPUT-OUTPUT |
AC 3,000V 1 minute current 20mA,DC
500V 100MΩ(At room temperature & Humidity) |
| INPUT-CASE,FG |
AC 2,000V 1 minute current 20mA,DC
500V 100MΩ(At room temperature & Humidity) |
| OUTPUT-CASE,FG |
AC 500V 1 minute current100mA,DC 500V
100MΩ(At room temperature & Humidity) |
| ENVIRONMENT |
OPERATING TEMP.AND HUMID. |
-10~50℃:100%, 50~60℃:70%, 20~90% RH(Non
Condensing) |
| STORAGE TEMP.AND HUMID. |
-20~+75℃, 20~90% RH(Non Condensing) |
| VIBRATION |
10~55Hz at 2G, 3 minutes period,30
minutes along X,Y and Z axis |
| IMPACT |
20G for 20ms, Once on each X,Y and
Z axis |
| SAFETY |
SAFETY REGULATION |
Complied with UL 60950, C-UL,EN60950 |
| LINE CONDUCTED RF VOLTAGE |
Complied with FCC Part 15, VCCI-B,CISPR22-B,EN55022-B |
| HARMONIC ATTENUATOR |
Complied with IEC61000-3-2 |
|
|
|
|
|
|
