| INPUT |
VOLTAGE(V) |
AC100~120V/200-240V (AC90~132V/180~264V
or DC240~370V), 50/60Hz (47~440Hz or DC) |
| CURRENT(A) |
100V ~4.4A,200V ~2.2A |
| FREQUENCY |
|
| EFFICIENCY |
75 % typ |
| INRUSH CURRENT |
20A typ(AC IN 110V, Io=100%),40A typ(AC
IN 220V, Io=100%)at cold start |
| OUTPUT |
VOLTAGE(V) |
12 |
| CURRENT(A) |
18.5 |
| REGULATION,LINE(mV) |
60 Max |
| REGULATION,LOAD(mV) |
120 Max |
| RIPPLE(mVP-P) |
120 Max |
| RIPPLE,NOISE(mVP-P) |
170 Max |
| TEMPRETURE DRIFT,0~+50℃(mV) |
180 Max |
| RISE TIME(mS) |
600 Max(AC IN 110V/220V Io=100%) |
| HOLDING TIME(mS) |
15 typ (AC IN 110V/220V Io=100%) |
| PROTECTION CIRCUIT |
OVERCURRENT PROTECTION |
Works at over 110% of rating and recovers
automatically |
| OVERVOLTAGE PROTECTION |
Works at 110~150% of rating |
| ELECTRICALLY ISOLATED |
INPUT-OUTPUT |
AC 3,000V 1 minute current 20mA, DC 500V
100MΩ(At room temperature & Humidity) |
| INPUT-CASE,FG |
AC 2,000V 1 minute current 20mA, DC 500V
100MΩ(At room temperature & Humidity) |
| OUTPUT-CASE,CASE |
AC 500V 1 minute current 100mA, DC 500V
100MΩ(At room temperature & Humidity) |
| ENVIRONMENT |
OPERATING TEMP.AND HUMID. |
-10~+50℃, 20~90% RH(Non condensing) |
| STORAGE TEMP.AND HUMID. |
-20~+75℃, 20~90% RH(Non condensing) |
| VIBRATION |
10~55Hz at 1G, 3 minutes period, 30 minutes
along X,Y and Z axis |
| IMPACT |
10G for 20ms once on each X,Y and Z axis |
| SAFETY |
SAFETY REGULATION |
UL,C-UL,CE |
| LINE CONDUCTED RF VOLTAGE |
|
|
